Plastic PBT Fixed Fiber Optic Attenuator SC / UPC 3dB 5dB 10dB , SC 15dB Attenautor

Tempat asal Cina
Nama merek YINGDA
Sertifikasi ISO
Nomor model ATTN-SCS-01-B03
Kuantitas min Order 100PCS
Harga Negotiable
Kemasan rincian 50 pc / plastic blister box or customized
Waktu pengiriman 3-5 days
Syarat-syarat pembayaran T/T or western Union
Menyediakan kemampuan 50,000pcs per month

Hubungi saya untuk sampel dan kupon gratis.

Ada apa:0086 18588475571

Wechat wechat: 0086 18588475571

Skype: sales10@aixton.com

Jika Anda memiliki kekhawatiran, kami menyediakan bantuan online 24 jam.

x
Detail produk
Attenuation 3dB wavelength range 1260-16500nm
test wavelength 1310nm, 1550nm material plastic PBT
Additional loss 0.1dB Working temperature -40~+85 (℃)
Fiber optic type single mode 9/125um standard GR910, IEC
connector SC/UPC connector color blue
Cahaya Tinggi

build out attenuator

,

optical fiber attenuator

Tinggalkan pesan
Deskripsi Produk

SC Fiber Optic Attenuator SC/PC SC/UPC 3dB 5dB 10dB, Fixed Attenautor SC 15dB





Fiber optic attenuators are used in the fiber optic communications to reduce the optical fiber power

at a certain level, the most commonly used type is female to male plug type fiber optic attenuator,

it has the optical fiber connector at one side and the other side is a female type fiber optic adapter,

fiber optic attenuator name is based on the connector type and the attenuation level.



 SC 3dB fiber optic attenuator means this attenuator uses SC fiber optic connector and it can reduce

the optical fiber power level by 7dB. Commonly used attenuation range is from 1dB to 25dB, and it is

also available to provid upto 30dB.





Main features

  • Connector style available in LC, FC, SC, ST and MU
  • High performance unit
  • Stable attenuation values
  • Customized to your volume requirements
  • Environmental stable



Applications



  1. Fiber in The Loop. (FITL)
  2. Passive Optical Networks
  3. Fiber to the Home. (FTTH)
  4. Test equipments
  5. LANs
  6. CATV
  7. Video distribution



Specifications



Operating Wavelength

SM:1200~1600nm, 1310nm, 1550nm, 1310/1550nm;

MM: 850nm, 1300nm



Attenuation Value

1~30dB

Connector Type

 FC, SC, LC, ST, MU, E2000, MTRJ

Return Loss

PC ≥50dB; UPC ≥55dB; APC≥ 65dB

Attenuation Accuracy

1~10dB ≤ ± 0.5dB; 11~20dB ≤ ± 1.0dB; 21~30dB ≤ ± 2.0dB

Maximum Optical Input Power

200mW

Operating Temperature

-40℃ ~ + 75℃

Storage Temperature

-40℃ ~ + 75℃
