FTTH CATV LC/PC Fiber Optic Adapter 4 Way Blue , SM / MM LC Optical Adapter

Produk

Fiber Optic sambatan penutupan

Modul SFP

Hubungi Kami

sales@yingdapc.cn

+86 18688982406

Hubungi Sekarang

FTTH CATV LC/PC Fiber Optic Adapter 4 Way Blue , SM / MM LC Optical Adapter

MOQ:	1000 pcs
harga:	0.04USD-2.15USD
Kemasan standar:	20 pcs / blister box
Periode Pengiriman:	3working days
metode pembayaran:	T/T or western Union
Kapasitas Pasokan:	100000pcs/month

Informasi Rinci

Deskripsi Produk

Peringkat & Ulasan

Informasi Rinci

Tempat asal

Nama merek

YINGDA

Sertifikasi

ISO,SGS

Model Number

AD-LC-SM-Q4

Fiber count:

4 Core, quad fibers

connector material:

plastic

connector color:

sleeve material:

ceramic

fiber type:

singlemode

polish mode:

UPC SPC

insertion loss:

<0.2dB

temperature:

-40~+80 °C

Nama produk:

kabel mpo ke mpo, kabel mpo ke lc, konektor optik mtp, kaset mtp

Menyoroti:

serat optik coupler

serat optik adaptor

Deskripsi Produk

Fiber Optic Adapter LC 4Way Blue, LC Optical Adapter, LC/PC Adpater SM / MM

Features

Conforms to Telcordia GR-326-CORE standard
Conforms to YD/T-1272.3 standard
Good interchangeability,low insertion loss
Easy to use,plug
Application: FTTH,CATV,Telecommunications,etc

This coupler provides a solution for extending a current run of fiber optic cabling. This coupler

is constructed from highgrade plastic and has been designed and engineered for durability

and a long life.

Adapter Drawing

FTTH CATV LC/PC Fiber Optic Adapter 4 Way Blue , SM / MM LC Optical Adapter 0

Material List:

Sleeve: Ceramic or PB
Housing: PC , Flammability UL94 V-0
Dust cap: PVC, Flammability UL94 V-0
Clip:s tainless steel

Optical characteristic

Optical Performance

Premium Grade

Standard Grade

Insertion Loss

≤0.1dB

≤0.2dB

Durability

1000 times

Environment and Mechanical Properties

Item	Test condition	Conformance	Test result
Vibration	10-55Hz, 1.5mm, 60min	IEC61300-2-1	≤0.2dB
Mating Durability	1000 Mating, clean every 25 mating.	IEC61300-2-2	≤0.2dB
Impact	1.5m, 8 drops	IEC61300-2-6	≤0.2dB
Strength of Coupling Mechanism	40N, 10Min, L=22-28cm	IEC61300-2-12	≤0.2dB
Temperature Cycling	40ºC to +75ºC, 40 cycles	IEC61300-2-22	≤0.2dB
Temperature humidty cycling	40ºC, 95%, 96Hr	IEC61300-2-21	≤0.2dB
Operating Temperature	-40ºC to +85ºC		≤0.2dB
Storage Temperature	-40ºC to +85ºC		≤0.2dB

More product show:

FTTH CATV LC/PC Fiber Optic Adapter 4 Way Blue , SM / MM LC Optical Adapter 1

Product application occasions: FTTH CATV LC/PC Fiber Optic Adapter 4 Way Blue , SM / MM LC Optical Adapter 5

Peringkat & Ulasan

Peringkat Keseluruhan

5.0

Berdasarkan 50 ulasan untuk pemasok ini

Cuplikan Peringkat

Berikut adalah distribusi dari semua peringkat

5 bintang

4 bintang

3 bintang

2 bintang

1 bintang

Semua Ulasan

1*x

Chile Aug 23.2023

Bermanfaat (9)

Good quality, IP65 waterproof. will continue to cooperate with YINGDA

D*e

Venezuela Sep 26.2022

Bermanfaat (24)

All connectors insert loss < 0.3db, and the quality is better than other suppliers. I recommend this supplier to everyone, very professional!

Mini Type Dome Fiber Optic Splice Closure for 48 Fiber Cable Joint closure

Turkey Jan 28.2022

Bermanfaat (2)

The team helped me from start to finish with this special order. Always updated on the status. With so many bad issues in the past, i was worried when buying items from alibaba, but for this one it went 100% ok. The order arrived as discussed and all perfect. Thank you.

Tag:

Produk

MOQ:	1000 pcs
harga:	0.04USD-2.15USD
Kemasan standar:	20 pcs / blister box
Periode Pengiriman:	3working days
metode pembayaran:	T/T or western Union
Kapasitas Pasokan:	100000pcs/month

Informasi Rinci

Deskripsi Produk

Informasi Rinci

Tempat asal

Cina

Nama merek

YINGDA

Sertifikasi

ISO,SGS

Model Number

AD-LC-SM-Q4

Fiber count:

4 Core, quad fibers

connector material:

plastic

connector color:

blue

sleeve material:

ceramic

fiber type:

singlemode

polish mode:

UPC SPC

insertion loss:

<0.2dB

temperature:

-40~+80 °C

Nama produk:

kabel mpo ke mpo, kabel mpo ke lc, konektor optik mtp, kaset mtp

Minimum Order Quantity:

1000 pcs

Harga:

0.04USD-2.15USD

Packaging Details:

20 pcs / blister box

Delivery Time:

3working days

Payment Terms:

T/T or western Union

Supply Ability:

100000pcs/month

Menyoroti

serat optik coupler

serat optik adaptor

Deskripsi Produk

Fiber Optic Adapter LC 4Way Blue, LC Optical Adapter, LC/PC Adpater SM / MM

Features

Conforms to Telcordia GR-326-CORE standard
Conforms to YD/T-1272.3 standard
Good interchangeability,low insertion loss
Easy to use,plug
Application: FTTH,CATV,Telecommunications,etc

This coupler provides a solution for extending a current run of fiber optic cabling. This coupler

is constructed from highgrade plastic and has been designed and engineered for durability

and a long life.

Adapter Drawing

FTTH CATV LC/PC Fiber Optic Adapter 4 Way Blue , SM / MM LC Optical Adapter 0

Material List:

Sleeve: Ceramic or PB
Housing: PC , Flammability UL94 V-0
Dust cap: PVC, Flammability UL94 V-0
Clip:s tainless steel

Optical characteristic

Optical Performance

Premium Grade

Standard Grade

Insertion Loss

≤0.1dB

≤0.2dB

Durability

1000 times

Environment and Mechanical Properties

Item	Test condition	Conformance	Test result
Vibration	10-55Hz, 1.5mm, 60min	IEC61300-2-1	≤0.2dB
Mating Durability	1000 Mating, clean every 25 mating.	IEC61300-2-2	≤0.2dB
Impact	1.5m, 8 drops	IEC61300-2-6	≤0.2dB
Strength of Coupling Mechanism	40N, 10Min, L=22-28cm	IEC61300-2-12	≤0.2dB
Temperature Cycling	40ºC to +75ºC, 40 cycles	IEC61300-2-22	≤0.2dB
Temperature humidty cycling	40ºC, 95%, 96Hr	IEC61300-2-21	≤0.2dB
Operating Temperature	-40ºC to +85ºC		≤0.2dB
Storage Temperature	-40ºC to +85ºC		≤0.2dB
