LC Mechanical VOA LC MVOA Fiber Optic Attenuator Single Mode For EDFA Power Amplifier
  • Nama
  • Nama
  • Nama
  • Nama

LC Mechanical VOA LC MVOA Fiber Optic Attenuator Single Mode For EDFA Power Amplifier

MOQ: 100PCS
harga: Dapat dinegosiasikan
Kemasan standar: 1 pc / plastoc bag
Delivery period: 3-5 days
metode pembayaran: T/T or western Union
Kapasitas Pasokan: 50,000pcs per month
Informasi Rinci
Deskripsi Produk
Peringkat & Ulasan
Informasi Rinci
Tempat asal
Cina
Nama merek
YINGDA
Sertifikasi
ISO
Model Number
ATTN-LCS-MVOA-01
Attenuation:
0-30dB Adjustable
test wavelength:
1310nm, 1550nm
body material:
metal
Additional loss:
0.1dB
Working temperature::
-40～+85 (℃)
Fiber optic type:
single-mode
connector type:
LC/PC
dust cap:
plastic white
house color:
plastic blue
Nama produk:
adaptor jaringan serat, kopling serat optik, adaptor konverter media, attenuator gelombang mikro, at
Menyoroti:

optical fiber attenuator

,

inline optical attenuator

Deskripsi Produk

LC Mechanical VOA Attenuator, LC MVOA Attenuator, Fiber Optic Attenuator





LC Mechanical variable optical attenuator is generally used in optical measurement. In the when

measure optical receiver sensitivity, usually place in the optical receiver input to adjust receiving

light power. It is in the middle of fiber connector, suitable for all kinds of fibre optic connector with

all high performance of connectors.





When use optical attenuator, please keep the environment clean and dry, put on the dust cap

when not in use, handle with care, strictly forbid collision.





Feature:

  1. Low PDL
  2. Attenuation 1dB to 30dB
  3. Compact size, light weight
  4. Low reflection loss
  5. High power tolerance,long-term stability
  6. Independent of the wavelength effect
  7. Precisely control attenuation range
  8. Simple operation
  9. Meet the GR910



Application:

  1. EDFA power amplifier
  2. The power balance in the system
  3. CATV
  4. Optical add-drop multiplexer in the optical power regulator



Specification:



Parameter

Condition

Value

Attenuation(dB)

UPC

1~30

APC

Return loss(dB)

UPC

>50

APC

>60

Operating wavelength(nm)

1310, 1550, 1240, 1600

Attenuation accuracy

1~4dB

≤0.5dB

5~30dB

<10%

Operating temperature()

-

-40 ~ +75

Storage temperature()

-

-40 ~ +85

Polarization Dependent Loss(dB)

-

<0.2

Relative humidity (%)

75

95

Vibration(dB)

10 ~55,2Hrs

∆IL≤0.2

Impact(dB)

1.5m,5 drops

∆IL≤0.2

LC Mechanical VOA LC MVOA Fiber Optic Attenuator Single Mode For EDFA Power Amplifier 0LC Mechanical VOA LC MVOA Fiber Optic Attenuator Single Mode For EDFA Power Amplifier 1
