Length 40mm Single - mode Bare Fiber Optic Adapter SC FC LC ST Metal Round
  • Nama
  • Nama
  • Nama
  • Nama

Length 40mm Single - mode Bare Fiber Optic Adapter SC FC LC ST Metal Round

MOQ: 100 PCS
harga: 0.04USD-2.15USD
Kemasan standar: 1 pc / bag or 10 pc/ blister box
Delivery period: 3 days
metode pembayaran: T/T or western Union
Kapasitas Pasokan: 50,000pcs per month
Informasi Rinci
Deskripsi Produk
Peringkat & Ulasan
Informasi Rinci
Tempat asal
Cina
Nama merek
YINGDA
Sertifikasi
ISO,SGS
Model Number
ADB-SC-RD
material:
Metal, Plastic
house color:
blue
shape:
round
type:
bare fiber optic adapter
weight:
12g
Fiber type:
single-mode
Nama produk:
kabel mpo ke mpo, kabel mpo ke lc, konektor optik mtp, kaset mtp
Menyoroti:

serat optik coupler

,

adapter serat telanjang

Deskripsi Produk

SC Bare Fiber Adapter, Bare Fiber Optic Adapter SC FC LC ST Metal Round





Description





FC SC LC ST Round Bare Fiber Adapter can link bared optic and light source ,testing equipment,

light appearance etc,and the products used for test appearance and temporary conjunction between

fiber optics extensively (repair fiber optic cable urgently). It have the bare optical fiber inside one side,

the other side is a connector that can plug into the equipment.



The optical fiber is connected through the opening sleeve inside adapter, in order to ensure the

highest performance of optical fiber jumper. In order to fixed on various panel, a variety of fixed

flange adapters design and manufactured.



Feature

  1. Simplex and quickly interconnect
  2. Low insertion loss
  3. Good repeatability and exchangeability good
  4. Stabilize the credibility
  5. Interchangeable connector heads available
  6. SC FC LC ST connectors available
  7. Cutomer package OK
  8. 10PCS/ blister box, save shipping cost



Application

  • Testing fiber on the reel
  • Optical fiber through connection test
  • Two-way communication during optical-fiber cable installation and maintenance
  • First-aid repair,temporary connection and testing on optical fiber project.



Specification



Shape

Square / Round

Connector

FC/PC, SC/PC, ST/PC, LC/PC

Applicable fiber

SM & MM

Ferrule diameter

123-127 um

Ferrule outder diameter

2.499mm 1.249mm

Cable diameter

250um & 900um

Insertion Loss

≤0.20dB

Repeat ability

＜0.2dB

Tensile strength

100g

Plug time

 >1000 times

Operating Temperature

-40 ~+85℃

Size

Length:40mm, diameter:30mm



Length 40mm Single - mode Bare Fiber Optic Adapter SC FC LC ST Metal Round 0Length 40mm Single - mode Bare Fiber Optic Adapter SC FC LC ST Metal Round 1Length 40mm Single - mode Bare Fiber Optic Adapter SC FC LC ST Metal Round 2Length 40mm Single - mode Bare Fiber Optic Adapter SC FC LC ST Metal Round 3







Peringkat & Ulasan

Peringkat Keseluruhan

5.0
Berdasarkan 50 ulasan untuk pemasok ini

Cuplikan Peringkat

Berikut adalah distribusi dari semua peringkat
5 bintang
100%
4 bintang
0%
3 bintang
0%
2 bintang
0%
1 bintang
0%

Semua Ulasan

T
T*s
South Africa Jun 20.2024
Bermanfaat (6)
Excellent product, easy connection, great quality, delivered on time, recommended for everyone!
Review Image
R
R*K
Venezuela Sep 26.2022
Bermanfaat (24)
All connectors insert loss < 0.3db, and the quality is better than other suppliers. I recommend this supplier to everyone, very professional!
Review Image
C
C*d
Ecuador Feb 26.2021
Bermanfaat (3)
Excellent quality, as always! Fantastic product and service!
Review Image
